FRONT SUSPENSION 3D-1
SECTION 3D
FRONT SUSPENSION
NOTE:
-All front suspension fagternors play a fundamental role, since they could affect the performance of the systems
and vital components, and/or cauld result in major repair expense. If some piece requires replacement, it
must be replaced with another one having the same part number, or equivalent. Do not use replacement part
of lesser quality. Or substitute design during the reassembling keep strictly to the specified torques, to ensure
the correct hold-up of the different parts.
-Never attempt to heat, quench or straighten any front suspension part. Replace it a new part or damage to the
part may result.
CONTENT
GENERAL DESCRIPTION .................................................................................................................................... 3D- 2
ON VEHICLE SERVICE ........................................................................................................................................ 3D- 3
Front leaf springs and shock absorbers ....................................................................................................... 3D- 3
Springs bush and body ............................................................................................................................... 3D- 6
Spring bumpers ........................................................................................................................................... 3D- 6
FRONT SUSPENSION INSPECTION ................................................................................................................... 3D- 7
TIGHTENING TORQUE SPECIFICATIONS .......................................................................................................... 3D- 8
DATA AND ASSEMBLY TOLERANCES ................................................................................................................ 3D- 8
