6C-12 ENGINE FUEL AND EMISSION CONTROL SYSTEM
Fuel level gauge
Removal
1) Prepare a recipient to receive the fuel remaining in tank and
pipes.
2) Remove fuel tand (see 6C-10).
3) Remove fuel level gauge (8).
NOTE:
Drain fuel in tank into a suitable recipientand check
for any distiness.
If there´s any, thoroughly clean the tank.
Inspection
1) Check inner float moving, presence of dirt, and electrical
response on instrument papel. If any problem is detected,
replace.
8
8
Installation
1) Reverse removal procedure, noting tighten to specified torque.
Fuel level gauge screws tightening torque:
0,5 Kg-m (5 Nm)
