9-4 BODY SERVICE

WINDOW REGULATOR

Removal

1) Remove regulator supporting plate and screws fixing the

regulator to the guide (see 9-2).

2) Withdraw the door regulator.

Inspection

1) Check sliding pieces greasing and regulator rotation.

2) Check for damages and wear in sliding cylinder and cable.

NOTE:

If you notice any faulty component, replace it.

Instalation

1) Reverse removal procedure ,noting specifications at the

complementary tasks.
