STEERING WHEEL, COLUMN AND LOWER SHAFT 3C-3
ON VEHICLE SERVICE
STEERING WHEEL
Removal
1) Disconnect negative battery cable.
2) Removal steering wheel cover (1) and nut (2) from the steering
column.
3) Do coincidental marks (A) on the steering wheel and the
steering column, to use them as a guide to assembly.
NOTE:
Such coincidental marks (A), are necessary only in the
case the steering wheel is going to be dismantled and
put back again.
4) Remove steering wheel using an appropriate extractor.
Installation
1) Install steering wheel over the column aligning the
coincidental marks (A) which you did when dismantling.
2) Tighten not (2) from steering column to the specified torque.
Tightening torque for the fixing nut of the steering
wheel: 2,5 ÷ 4 Kg-m (25 ÷ 40 Nm)
3) Install steering wheel cover (1) and connect back the battery.
4) Run straightforward the vehicle for a short distance, to confirm
the correct positioning of the steering wheel.
2
1
2
1
A
