HEATER AND VENTILATION 1A-3
HEATER CONTROL OPERATION
The correct handling of the heating system control is based on
the use and proper handle of four levers.
• Control lever A
Control lever A has three working positions:
• Ventilation position (1)
• Ventilation and demisting position (2)
• Demisting position (3)
• Control lever B
Control lever B has two working positions:
• Air circulation position (4)
• Fresh air position (5)
• Control lever C
Control lever C is temperature control lever.
Air temperature can be controlled moving the lever to the
chosen temperature.
• Displaced totally to the left, maximum hot air
• Displaced totally to the right, maximum fresh air
1 2
3
4
5
A
B
C
