3C-2 STEERING WHEEL, COLUMN AND LOWER SHAFT
GENERAL DESCRIPTION
The steering column can be easily dismantled or reassembled. To ensure the adequate energy damping, it is important to
use only the original SANTANA fixing elements, and tightening up to the specified torques.
When dismantling the vehicle steering ensemble, attention must be paid to carefully handling. The eventual sharp hitting
at the end of the axle ensemble or the accidental falling of such ensemble could lead to the breaking of the security plastic
pins holding the steering column and lower shaft.
1. Steering wheel.
2. Steering wheel cover.
3. Steering column assembly.
4. Steering lower shaft.
5. Steering column upper cover.
6. Steering column lower cover.
5
6
2
3
1
4
