ENGINE REPAIR 6A-13
Concept
Cycle
Supply
Injection
Cylinders number
Diameter
Course mm
Total cylinder capacity cm
3
Compression ratio
Maximum power kW
(CV)
r.p.m.
Maximum torque Nm
(Kgm)
r.p.m.
Minimum rpm regime of engine without
loading
r.p.m.
Cylinder head valves location.
Four strokes Diesel
Oversupplied
Directly
4 in line
94,4
100
2800
FRENTE
T.D.C.. pressure
*bar
T.D.C. minimum allowed pressure
*bar
18,5
3600
1800
20 ± 2,6
16
E = Exhaust
A = Admission
Maximum rpm regime of engine without
loading
r.p.m.
4200 ± 50
(*) Pressure value is read starting the engine using an auxiliary starting electric motor, with oil at temperature between
40 and 50 °C and pump set-up in stop.
ID = Direct Injection
TCA = Intercooler over supplying
GENERAL CHARACTERISTICS
MECHANICAL
INJECTION
8140.43C.3
COMMON RAIL
8140.43S.4ID/TCA
75,5 ÷ 80,5
102,7 ÷ 109,5
88,8 ÷ 95,2
120,8 ÷ 129,5
250
25,5
275,5 ÷ 304,7
28,1 ÷ 31,1
750 ± 25 800 ± 25
