REAR SUSPENSION 3E-1
SECTION 3E
REAR SUSPENSION
CONTENT
GENERAL DESCRIPTION ..................................................................................................................................... 3E- 2
ON VEHICLE SERVICE ......................................................................................................................................... 3E- 3
Rear leaf springs and shock absorbers ......................................................................................................... 3E- 3
Leaf springs and chassis bumpers ............................................................................................................... 3E- 4
Springs bumpers .......................................................................................................................................... 3E- 4
REAR SUSPENSION INSPECTION ....................................................................................................................... 3E- 5
TIGHTENING TORQUES ESPECIFICATIONS ....................................................................................................... 3E- 6
ASSEMBLY DATA AND TOLERANCES ................................................................................................................. 3E- 6
NOTE:
- All suspension fasteners are an important attaching part in that it could affect the perfomance of vital parts
and system, and/or could result in major repair expense. They must be replace with one of the same part
number or whith an equivalent part if replacement becomes necessary. Do not use replacement part of lesser,
quality or susbstitute design. Torque values must be used as specified during reassembly to assure proper
retention of this part.
- Never attempt to heat, quench or straighten any suspension part. Replace it with a new part, or damage to the
part may result.
3E
