ENGINE REPAIR 6A-23

SYMBOL CHART

Surface to be worked

Finishing

Interference

Forced installation

Thickness

Play

Intake

Exhaust

Running

Compressure Ratio

Preloading

Number of revolutions

Pressure

Oversize

Higher than ...

Undersize

Less than...

Selection

Classes

Oversizes

Temperature < 0 ºC

Cold

Winter

OF FORM

Circularity

Cylindricality

Parallelism

Perpendicularity

Concentricity or coaxiality

Circled Oscillations

Total Oscillation

OF ORIENTATION

OF LOCATION

OF OSCILLATION

CLASS ATRRIBUTED TO THE CHARACTERISTICS OF THE PRODUCT

GRAPHIC SYMBOL

TOLERANCES CHARACTERISTICS, GRAPHIC SYMBOL

CRITICAL

IMPORTANT

SECONDARY
