7D-16 TRANSFER BOX

SPEEDOMETER CABLE REPLACEMENT

1) Disconnect speedometer cable (1) from speedometer gear

box.

2) Remove steering wheel outer cover (2).

3) Remove dashboard cover.

4) Remove screws (4) and dashboard (5).

5) Disconnect speedometer cable from dashboard.

6) Replace speedometer cable with a new one and replace the

components in reverse order to the removal.
