FRONT DRIVE SHAFT 4A-11
FRONT SHAFT HOUSING SUBSTITUTION
Removal
1) Remove left and right steering pivot assemblies (see 4A-3).
2) Remove differential group (see 4A-5).
3) Remove U-bolts (1) and withdraw housing (2).
3
Installation
1) Install a new housing and fix it with U-bolts tightening nuts
to the specified tightening torque.
Tightening torque for U-bolts nuts:
7Kg-m (70 Nm)
2) Install new oil-seals (3) on the housing and apply grease
into the enclosing lips.
3) Continue install the differential group and steering pivots as
indicated in complementary task
1
2
