Santana PS-10 User Manual

CLUTCH 7C-15
TORQUE
ASSEMBLY DATA AND TOLERANCES
SERVICE LIMIT
NEW
0,25 mm
0,50 mm
3,04 mm
0,25 mm
140 mm
15 ÷ 20 mm
REQUIRED SERVICE MATERIALS
Setscrews - pressure plate
2,75 ÷ 3,75
Fixing nuts - main cylinder control rod
2 ÷ 2,5
Fixing nuts - auxiliary cylinder 2,2 ÷ 2,5
27,5 ÷ 37,5
20 ÷ 25
22 ÷ 25
ELEMENT
TORQUE
Kg-m Nm
Contact surface wear - pressure plate
Contact zone wear - diaphragm and thrust block
Clutch disc facing wear
Clutch disc warping
Clutch pedal height
Clutch pedal free travel
REF.
PRODUCT TYPEAPPLICATION POINT
Clutch hydraulic circuit
DOT- 4
DENOMINATION
Play between rod and main clutch pump
1,5 mm
791007
