9-18 BODY SERVICE
SIDES
Removal
1) Remove the corresponding rear side seat.
2) Remove trim and internal fittings from the corresponding side.
3) Remove vehicle roof (see 9-11).
4) Remove the corresponding seat belt (see 9-25).
5) Remove nuts (1) fixing side (2) to rear body (3).
NOTE:
For the right hand side, dismantle screws (4) fixing back
door upper hinge (5) to side.
Instalation
1) Reverse removal procedure, noting the remarks on the
complementary tasks.
1
2
3
5
4
