STEERING WHEEL, COLUMN AND LOWER SHAFT 3C-1
SECTION 3C
STEERING WHEEL, COLUMN AND
LOWER SHAFT
NOTE:
• All fastening pieces of the steering wheel and the column play a fundamental role, as the could affect the
performance of the essential systems and components, and/or lead to considerable reparse fees. If any piece
requires replacement, it must be substituted by another piece having the same serial replacement number, or
equivalent. Do not use substitutes neither replacement pieces of lesser quality. During reassembling the specified
torques must be strictly applied, to be sure of the correct clamping of the different parts.
• To diagnostic failures on the different components which could bring about anomalous behaviours of the
general steering system, see carefully "CHART OF GENERAL DIAGNOSTICS (3-2-2)".
CONTENT
GENERAL DESCRIPTION ..................................................................................................................................... 3C- 2
ON VEHICLE SERVICE ......................................................................................................................................... 3C- 3
Steering wheel ............................................................................................................................................. 3C- 3
Steering wheel repositioning ......................................................................................................................... 3C- 4
Combination switch, wind screen wipers and horn ........................................................................................ 3C- 5
Ignition switch and steering look assembly .................................................................................................. 3C- 6
Steering lower shaft ..................................................................................................................................... 3C- 8
Steering articulated rod ................................................................................................................................ 3C-10
CHECKING STEERING COLUMN FOR ACCIDENT DAMAGE ................................................................................ 3C-11
TIGHTENING TORQUE SPECIFICATIONS ........................................................................................................... 3C-12
DATA AND ASSEMBLY ALLERANCES ................................................................................................................. 3C-12
