MAINTENANCE AND LUBRICATION 0B-11
Water Radiator (Item 1.6)
External Cleaning
• External cleaning of the water radiator (1) must be done
with pressurized water, compressed air and a brush no
harming the refrigerating panel.
• Do not use sharp pointed objects which could damage the
refrigerating panel.
• If it is necessary to remove the intercooler (2) to easy the
cleaning tasks, disconnect the rigid interconnecting pipe
of the sleeves; union to the air channelling: disconnect the
four nuts holding the intercooler to the water radiator and
remove it without disconnecting the air conduction sleeves.
Intercooler (Item1.7)
External Cleaning
• Do the external cleaning of the intercooler (2) (air radiator)
using the same methods as those used when doing the
external cleaning of the water radiator.
Air Filter (Item 1.8)
Residues purging, cleaning and substitution of
the filtrating element.
• To purge the accumulated residues on the filter seat (purer
(1)), and also for the cleaning or substitution of the filtrating
element see 6C-48 "MANIPULATING THE AIR FILTER ".
1
2
1
