BODY SERVICE 9-7
BACK DOOR
DOOR GLASS AND LATERAL WINDOW
Removal
1) Clean around the internal and external sides of glass.
2) Remove spare wheel.
3) Stick band at the body, around the glass, to avoid possible
damages when extracting and assembling the glass.
4) Disconnect defrosting electrical heating pad.
5) Remove expanding strip (1).
Instalation
NOTE:
• If the weather strip to be fixed has been provided as
a roll, slice a piece having the glass perimeter plus a
25 mm excess in order to be sure there will be a
proper fitting of the glass when installed.
• Do the cutting at right angles with some sort of fretting
saw.
1) Fit weather strip to the frame border noting to the curved
areas coupling and press the weather strip till any leftovers
made while cutting it get properly fitted.
6) Using an appropriate punch, Remove weather strip (2) and
glass (3).
1
2
3
