1BODY ELECTRICAL SYSTEM 8-
SECTION 8
BODY ELECTRICAL SYSTEM
CONTENT
GENERAL DESCRIPTION ...................................................................................................................................... 8- 1
Wiring ........................................................................................................................................................... 8- 1
OVERALL WIRING SCHEMES ............................................................................................................................... 8- 2
GENERAL DESCRIPTION
The electrical components of this vehicle are designed to work at 12 volts from electric battery system and the negative
terminal as ground or earth.
WIRING
To ease identification of each of the circuit a colour code is used.
