ENGINE FUEL AND EMISSION CONTROL SYSTEM 6C-17
10.- TRANSFER PRESSURE COURSE
Overfeed pressure hPa: 1200
1- Regime r/min: 900
Transfer pump
pressure bar: 5,9 ± 0,3
2- Regime r/min: 1800
Transfer pump
pressure bar: 8,3 ± 0,5
3- Regime r/min: 600
Transfer pump
pressure bar: 4,9 ± 0,5
11.- OUTLET VOLUME ON VALVE
1- Regime r/min: 600
Overfeed pressure hPa: 1200
Outlet volume c.c/10s: 113,9 ÷ 147,1
c.c/10s: (108,3 ÷ 157,7)
2- Regime r/min: 1800
Overfeed pressure hPa: 1200
Outlet volume c.c/10s: 144,4 ÷ 188,8
c.c/10s: (138,9 ÷ 194,3)
12.- FLOW AND REGULATION COURSE
1- Regime r/min: 500(*)
Overfeed pressure hPa: 500
Flow for 1000 deliveries cm
3
: 48,5 ± 0,5
cm
3
: ( ± 3,5)
2- Regime r/min: 2230
Overfeed pressure hPa: 1200
Flow for 1000 deliveries cm
3
: 15 ± 1,5
cm
3
: ( ± 2,0)
3- Regime r/min: 2100
Overfeed pressure hPa: 1200
Flow for 1000 deliveries cm
3
: 21,0 ± 6,0
cm
3
: ( ± 8,0)
4- Regime r/min: 2000
Overfeed pressure hPa: 1200
Flow for 1000 deliveries cm
3
: 43,0 ± 5,0
cm
3
: ( ± 4,5)
5- Regime r/min: 1800
Overfeed pressure hPa: 1200
Flow for 1000 deliveries cm
3
: 58 ± 2,5
cm
3
: ( + 3,5)
6- Regime r/min: 1100
Overfeed pressure hPa: 1200
Flow for 1000 deliveries cm
3
: 57,5 ± 0,5
cm
3
: ( ± 3,5)
7- Regime r/min: 600
Overfeed pressure hPa: 1200
Flow for 1000 deliveries cm
3
: 60,5 ± 4,0
cm
3
: ( ± 6,0)
8- Régimen r/min: 550
Overfeed pressure hPa: 0
Flow for 1000 deliveries cm
3
: 28,5 ± 0,5
cm
3
: ( ± 3,5)
13.- NO FLOW (STOP)
1- Electric
Regime r/min: 350
Flow for 1000 deliveries cm
3
: 1,5 ± 1,5
Voltage: volt: 0
14.- MINIMUN REGIME FLOW
1- Regime r/min: 350
Flow for 1000 deliveries cm
3
: 10,0 ± 2,0
cm
3
: ( ± 4,0)
15.- AUTOMATIC START SUPPLEMENTARY FLOW
1- Regime r/min: 100
Flow for 1000 deliveries cm
3
: 75,0 ± 20,0
cm
3
: MIN 55
2- Regime r/min: 370
Flow for 1000 deliveries cm
3
: 55,0 ± 20,0
cm
3
: MAX 70
16.- STOP ELECTRO-MAGNET
Minimun voltage of:
functioning volt: 10
nominal voltage volt: 12
17.- ASSEMBLY AND REGULATION MEASURES
Denomination:
K mm: 3,6 ± 0,1
MSI mm: 0,8 ± 0,1
Y
a
mm: 34,0 ± 1,0
Y
b
mm: 47,0 ± 3,0
Appliances:
LDA PLAY mm: 5,0
KSB LEVER mm: 5,71
KSB ADVANCE DEGREES A.P. : 2,0
NOTA:
• The bench measures are carried out with the KSB appliance at rest.
• For the regulation of the LDA, act on the preload spring washer.
• With each variation of LDA pressure, operate the control lever.
Injectors adjustment
BOSCH injector
SACLESS DSLA 134 P 604
Adjustment for Controls with values below to 200 bar 230 + 8 bar
Functioning adjustment 240 + 12 bar
