3B-6 STEERING GEAR BOX AND LINKAGE

TIE ROD

Removal

1) Remove the tie rod as you do with the drag rod (see 3B-4).

2) Remove in drag rod end ball joints and check them (see

3B-4).

Installation

1) Install tie rod end ball joints (see 3B-4).

2) Install tie rod as you do with the drag rod (see 3B-4).

3) Check convergence of wheels and carry out the appropriate

adjustments (see 3A-4).
