Santana PS-10 User Manual

7D-8 TRANSFER BOX
4WD SWITCH REPLACEMENT
Removal
1) Disconnect 4WD back up light cable (1) and the switch (2)
found in the front cover of the transfer box.
NOTE:
To disconnect the cable (1), press the fixing clip (3)
and move outwards.
2) Dismount 4WD switch (2).
Installation
1) Fit the 4WD switch and tighten to the specified torque
Torque for 4WD switch:
2 Kg-m (20 Nm)
2) Connect the double traction back up light cable (1) to the
4WD switch.
1
2
3
