MANUAL TRANSMISSION 7A-1
SECTION 7A
MANUAL TRANSMISSION
CONTENTS
GENERAL DESCRIPTION ..................................................................................................................................... 7A- 1
DIAGNOSIS ........................................................................................................................................................... 7A- 5
ON-VEHICLE SERVICE ......................................................................................................................................... 7A- 6
Gear and transfer shift lever .......................................................................................................................... 7A- 6
Dismounting and remounting of transmision assy and transfer box assy ...................................................... 7A- 8
GENERAL REPAIR OF TRANSMISSION .............................................................................................................. 7A-12
Disassembling and assembling of the transmission and transfer box ........................................................... 7A-12
Repairing the transmision ............................................................................................................................. 7A-13
TIGHTENING TORQUE SPECIFICATIONS ........................................................................................................... 7A-38
DATA AND ASSEMBLY TOLERANCE ................................................................................................................... 7A-39
REQUIRED SERVICE MATERIALS ....................................................................................................................... 7A-39
SPECIAL TOOLS .................................................................................................................................................. 7A-40
7A
NOTE:
The unions between cases or covers, can be carried out by product sealant or by gasket. During the assembly,
apply in each case recommended sealant or new gasket, as it proceeds

Santana PS-10 Specifications

General

Brand	Santana
Model	PS-10
Category	Automobile
Language	English
