REAR DRIVE SHAFT 4B-3
ON VEHICLE SERVICE
REMOVAL AND INTALLATION DIFFERENTIAL
GROUP
Removal
1) Place the vehicle in an appropriate working place to carry
out this task.
2) Removal oil emptying plug (1) and levelling plug (2) of the
rear differential group (2) letting all the oil out.
3) Clean the emptying plug thread as well as the corresponding
lodging thread in the housing. Install emptying plug applying
recommended sealant in the thread.
7) Remove nuts (6) and withdraw differential group (7).
1
2
5
3
7
6
4
4) Remove rear propeller shaft (see 4C-7).
5) Remove screws (4) fixing driving flange (3).
6) Remove at both sides, as an assembly, flange (3) and rear
shaft (5).
