ENGINE FUEL AND EMISSION CONTROL SYSTEM 6C-11
Fuel tank pressure control valve
Removal
1) From below, remove screw (9) which fixes the valve (11) to
the filler (10).
2) Disconnect pipe (12) and remove valve with its pipes.
10
9
11
12
Inspection
1) Blowing strongly from the tank side (14, black), the air should
come out the other end; if this is not the case, the valve
needs to be replaced.
2) Blowing normally from the atmosphere side (13, orange) the
air should easily come out the other side; if this is not the
case, or if it is necessary to blow hard, the valve (11) should
be replaced.
14
13
11
TANK
ATMOSPHERE
Installation
1) Install in reverse order to the dismantling, noting the position
of the valve (black side towards the tank, orange side towards
the atmosphere).
