6A-46 ENGINE REPAIR
BEARING OF GEARBOX PRIMARY AXLE
REMOVAL
Removal
1) Remove:
• Gear box assembly (see 7A-9).
• Pressuring plate and clutch disc assembly (see 7C-10).
2) Block adequately flywheel from turning.
3) Remove screws (2) and remove bearing support plate (1).
Bearing replacement
4) Substitute bearing (3) using a hydraulic press (A) and an
appropriate extractor (B).
Installation
1) Proceed to install reversing removal procedures; apply
specified tightening torque and those indicated in
complementary tasks.
Tightening torque for screws of bearing support plate:
1,8 ÷ 2,8 Kg-m (18 ÷ 28 Nm)
3
A
B
3
A
B
DISMANTLING
ASSEMBLY
1
2
