BRAKES 5-17
BRAKE FLUID SUBSTITUTION AND CIRCUIT
PURGING
CAUTION:
Brake fluid is extremely damaging paint. If fluid
should accidentally touch painted surface,
immediately wipe fluid from paint and clean painted
surface.
Fluid Substitution
1) Attach a vinyl tube (1) with an end connected to the brake
caliper purger (2) (of one of the four wheels) and the other
end introduced in an empty container.
2) Press a few times the brake pedal and keeping it pressed,
loose purging screw (2).
3) Keep pressed brake pedal till circuit lose pressure.
Circuit purging
1) Fill tank (3) with new brake fluid and keep it half full while
purging.
4) Fill tank (3) with new recommended fluid and keep it half full
substitution of the fluid is carried out.
5) Remove fluid through wheel purger till new fluid comes out.
6) Do above task in the other wheels.
7) When brake fluid has been replaced proceed to purging the
circuit.
3
1
2
