MAINTENANCE AND LUBRICATION 0B-23
Liquid Level
1) Brake liquid level must be on the line (A) (MAX) of the tank
(1); otherwise, add up till reaching the maximum level (MAX).
CAUTION:
Use new recommended brakes liquid.
NOTE:
If liquid was withdrawn from the circuit leading to the
formation of air bubbles, you will have to air purge
after filling.
Liquid Substitution and air purging
To carry out the brakes liquid substitution and the air purging,
see 5-17.
CAUTION:
• Do not use again the spent liquid neither the one
coming from air purging.
• Use always new recommended clutch liquid.
Recommend Brakes Liquid
A
1
Parking Brake (Item 4.3)
Performance Inspection
Check the performance of the tensioned parking brake. To do it
place the vehicle in a pronounced ramp and check that it holds
when the lever is located at the ratchet position 6 or 7; otherwise,
carry out the adequate tensioning operation (see 5-15).
Maximum performance of the parking brake:
Ratchet n° 7 of the lever
DOT-4
