4A-22 FRONT DRIVE SHAFT
TIGHTENING TORQUE SPECIFICATIONS
Screws fixing dragging flange
3.5 ÷ 4.25
Nut fixing tie rod end
4
Screws fixing brake caliper to support 3.1 ÷ 3.5
Nuts fixing wheel
Nuts fixing the differential group
35 ÷ 42.5
40
31 ÷ 35
ELEMENT
TORQUE
Kg-m Nm
Screws fixing the propeller shaft
2.8 ÷ 3.5
Nuts fixing leafd springs bolts
Nuts fixing the springs U-bolts
28 ÷ 35
Screws fixing extension case oil-seal of the hemisphere
Screws fixing the flange
Hub counter nut
Screws fixing lower and upper rotation axles
7
Screws/Nuts fixing assy flange steering pivot or hemisphere
Nut fixing engaging pinion flange
70
11 ÷ 17
110 ÷ 170
Screws fixing brake caliper support 6.5 ÷ 7.5
65 ÷ 75
9.5
7
95
70
3.5 ÷ 4.25
35 ÷ 42.5
0.8 ÷ 1.1
8 ÷ 11
3.5 ÷ 4.25
35 ÷ 42.5
12 ÷ 14
120 ÷ 140
3.5 ÷ 4.25
35 ÷ 42.5
ASSEMBLY DATA AND TOLERANCES
CONCEPT
DATA
Resistance to rotation or preloading of rotation axle bearings
(Measured without hemisphere oil-seal neither bushing)
2 ÷ 2,5 Kg
Hub longitudinal play
0,05 ÷ 0,10 mm
Drive shaft longitudinal play
0,12 ÷ 0,25 mm
11.75
117.5
