3C-6 STEERING WHEEL, COLUMN AND LOWER SHAFT
IGNITION SWITCH AND STEERING LOCK
ASSEMBLY
Removal
1) Remove steering wheel (see 3C-3).
2) Remove combination switch and wind screen wiper (see
3C-5).
3) Disconnect coupler (1) from the instrument panel wiring
connector.
4) Remove slave screw (2) fixing the ignition switch assembly
(3) to the steering column.
5) Turn ignition switch to position (1ª), to disengage the steering
lock assembly, and remove the ignition key assembly (3).
3
3
1
2
