BODY SERVICE 9-25
Removal
NOTE:
When replacing safety belt, change both the fixing buckle
and the belt retractor, with emergency blockage. This must
be done to be sure both the buckle and the small tongue
close properly.
If pieces were changed individually, if could happen that
they do not assemble properly.
1) Remove screws fixing safety belt ensemble to body.
2) Remove safety belt ensemble.
Instalation
1) Assemble safety belt unit reversing the dismantling order.
INSPECTION
Seat belts and fixing pieces might affect to important components
and systems of the vehicle.
Consequently, they must be carefully inspected and substituted
only by original pieces.
Inspect the followings components:
• Seat belt.
The strip or belt must be free.
• Retractor.
Should block the strip when pulling it fast. Beside, the
retractor should block strip when strip is inclined (approx
15°) in a longitudinal or transversal direction.
• Anchoring bolt.
Anchoring bolts must be tightened to the specified values.
• Belt hook.
Must stay blocked adequately.
