Santana PS-10 User Manual

TRANSFER BOX 7D-15
REMOVAL AND INSTALLATION OF TRANSFER
BOX ASSEMBLY
Removal
1) Drain oil from the transfer box (see 7D-6).
2) Remove the intermediate (2nd segment) segment of the
exhaust pipe.
3) Disconnect:
• Transmission clamps.
• Speedometer cable (see 7D-16).
• Parkingbrake drive rod (see 7D-9).
4) Remove transfer lever (see 7D-6).
5) Disconnect 4WD switch cable (see 7D-8).
6) Separate transfer box from gear box (see 7A-13).
Installation
1) Join the gear box to the transfer box, noting the torque specific
to each task (see 7A-12).
2) Connect the 4WD switch cable.
3) Fit the rest of the components in reverse order to the removal,
noting the torque specific to each task.
