6A-22 ENGINE REPAIR
Concept
Ø
Plungers in normal cylinder head
Ø normal
Adjusting plate
Between plungers and lodgings
H
Height of cams:
H
H
BELTS TENSION
Driving Belt Alternator and Water Pump
Tension
Driving Belt Air Conditioning Compressor
Tension
Timing Belt
Tension
43,950 ÷ 43,970
0,035 ÷ 0,081
From 3.25 till 4.45 mm
In progression of 0.05
9,5
10,5
140 ± 50 Hz
160 ± 10 Hz
Belt in HSN (High Strength Nitrile), with
Frecuency metre, must be 88 - 112 Hz
MECHANICAL
INJECTION
8140.43C.3
COMMON RAIL
8140.43S.4ID/TCA
