Santana PS-10 User Manual

ENGINE REPAIR 6A-21
Concept
Between valve seat
and cylinder head
H
H 1
H 2
H
H 1
H 2
ØØØ
Ø 2
Ø 1
Ø 3
Ø
Exernal sping of valves height
Free spring H
Under load of :
Kg 43,8 ± 2,5 H 1
Kg 77,4 ± 4 H 2
Valves internal spring of height:
Free spring H
Under load of :
Kg 16,4 ± 1 H 1
Kg 30 ± 1,5 H 2
X
Coming out of injectors X
Seats for connecting rods bush
normal Ø
oversized Ø
Journal of camshaft support
normal Ø
oversized Ø
Between seats and journal of
support:
Housing of plungers in normal
cylinder head
Ø normal
0,070 ÷ 0,135
0,080 ÷ 0,130
52
38,5
28,5
45,5
33,5
23,5
2,230 ÷ 2,690
33,985 ÷ 34,015
34,185 ÷ 34,215
33,934 ÷ 33,950
34,134 ÷ 34,150
0,035 ÷ 0,081
44,000 + 44,025
MECHANICAL
INJECTION
8140.43C.3
COMMON RAIL
8140.43S.4ID/TCA
3,7 ÷ 4,3
