Santana PS-10 User Manual

6A-20 ENGINE REPAIR
Concept
Valves housing guides in
cylinder head Ø 1
Ø 2
Valve guides
Ø 3
CYLINDER HEAD
Ø 2
Ø 3
Ø 4
a
a
Ø 4
a
Ø 4
Valves:
Valve guides and housings in
cylinder head
Valve guídes
Housing in cylinder head for
valve seat:
Ø 1
Ø 1
Ø 1
Linkage of valves and corresponding
guide
Ø ext of valves seats; inclinat. seats
valves regard to cylinder head
Ø 2
Ø 2
X
X
X
a
Ø 2
12,950 ÷ 12,985
8,023 ÷ 8,038
13,012 ÷ 13,025
0,027 ÷ 0,075
0,05 - 0,10 - 0,20
7,985 ÷ 8,000
60º 15´ ± 7´30´´
7,985 ÷ 8,000
45º 30´± 7´30´´
0,023 ÷ 0,053
42,125 ÷ 42,175
37,380 ÷ 37,415
42,245 ÷ 42,260
60º ± 5´
37,495 ÷ 37,510
45º ± 5´
a
a
1,2 ÷ 1,5
1,0 ÷ 1,3
Sinking
>
Ø1
MECHANICAL
INJECTION
8140.43C.3
COMMON RAIL
8140.43S.4ID/TCA
