Santana PS-10 User Manual

ENGINE REPAIR 6A-19
Concept
Measured height X
Maximum error on parallelism of
connecting rods axles =
X
Journal of Main bearing Ø 1
nº 1-2-3-4
nº 5
Journal of connecting rod Ø 2
Half ball bearings of main
bearing S 1*
Half ball bearings of
connecting rods S 2*
* Supplied as spare parts
Supports of main bearings Ø 3
nº 1-2-3-4
Support of main bearing n° 5
Half ball bearings - journal of main
bearings
Half ball bearings - journal of main
bearings
Half ball bearings of main bearings
Half ball bearings of connecting rod
Journal of axial main bearings X 1
Axial support of main bearing X 2
Axial half ball bearings X 3
Axial Support of crankshaft
X 3
0,09
80,182 ÷ 80,208
86,182 ÷ 86,208
56,515 ÷ 56,538
2,165 ÷ 2,174
1,875 ÷ 1,884
84,588 ÷ 84,614
90,588 ÷ 90,614
0,032 ÷ 0,102
0,035 ÷ 0,083
0,254 ÷ 0,508
0,254 ÷ 0,508
31,000 ÷ 31,100
26,500 ÷ 26,550
30,900 ÷ 30,950
0,060 ÷ 0,310
<
Ø1
Ø2
S1
S2
Ø3
X1
X2
MECHANICAL
INJECTION
8140.43C.3
COMMON RAIL
8140.43S.4ID/TCA
0,07
125
