Santana PS-10 User Manual

6A-18 ENGINE REPAIR
Concept
Tipe of piston
X 1*
Slits for elastic piston rings
X 2
X 3
* measured over Ø of 91.4 mm
X 1
X 2
X 3
S 1
S 2
S 3
S 1*
Elastic Piston rings S 2
S 3
*measured over Ø of 91.4 mm
1
Slits - Elastic piston rings 2
3
Elastic Piston rings
X 1
X 2
X 3
Openings end points of elastic piston rings
in liners of cylinders
X 1
X 2
X 3
Bush housing of the
connecting rod foot Ø 1
Ball bearings housing
of connecting rod * Ø 2
*connecting rod supplied as spare parts
Ø1
Bush diametre of connecting rod foot
external Ø 4
internal Ø 3
Half ball bearings of connecting rod
supplied as spare parts.
Bush of connecting rod foot - housing
Piston-bush bolt
Half ball bearings of connecting rod
MONDIAL PISTON AND KS
2,200 ÷ 2,230
2,050 ÷ 2,070
2,540 ÷ 2,560
2,068 ÷ 2,097
1,970 ÷ 1,995
2,470 ÷ 2,490
0,103 ÷ 0,162
0,055 ÷ 0,100
0,050 ÷ 0,090
0,4
0,20 ÷ 0,35
0,30 ÷ 0,50
0,30 ÷ 0,55
35,460 ÷ 35,490
60,341 ÷ 60,348
35,570 ÷ 35,595
32,010 ÷ 32,020
1,875 ÷ 1,884
0,08 ÷ 0,135
0,014 ÷ 0,03
0,254 ÷ 0,508
>
>
Ø2
Ø4
Ø3
S
MECHANICAL
INJECTION
8140.43C.3
COMMON RAIL
8140.43S.4ID/TCA
