6A-14 ENGINE REPAIR
Concept
TIMING
Beguinning before T.D.C. A
End after L.D.A. B
Beguinning before L.D.A. D
End after T.D.C. C
For control of fixing phase
mm
X
mm
Of running
mm
X
mm
{
{
FUEL SUPPLY
Injection pump type BOSCH
Regulator of the speed
Cooled start
Putting in phase of pump with piston in
T.D.C.
beguinning of the injection mm
Sprayer type
BOSCH
Injection Sequency
- injection pump
- engine
Working pressure injectors
* During the control operations, for values under 200 bar, calibrate injectors at 230 + 8 bar.
8º
37º
48º
8º
0,5 ± 0,05
0,5 ± 0,05
0,5 ± 0,05
0,5 ± 0,05
Rotative timing
VER (6C)
All regimes
K.S.B. electro-mechanical
1,10 ± 0,05
SACLESS
DSLA 134 P 604
A - B - C - D
1 - 3 - 4 - 2
240 + 12*
X
X
MECHANICAL
INJECTION
8140.43C.3..
COMMON RAIL
8140.43S.4ID/TCA
Of high pressure
Electroinyectores
DSLA 136 P 804
1350 Maximum
(electroinjector)
centralita EDC MS6.3
