ENGINE REPAIR 6A-31
NOTE:
• Nut (10) fixing hub must be replaced each time
removal takes place, and threads left wise.
• If Air conditioning is available, place a threaded rod
at hole (22) to fix the tensioning support of
compressor driving belt.
• To adjust tension of compressor driving belt, (see 6A-
27).
2) Apply specified tightening torque and those specified in the
complementary tasks.
Tightening torques:
• Nut (10) for hub (threads left wise)
Pre tightening: 4 Kg-m (40 Nm)
Angular tightening: 110º ± 10º
• Screw (20) fixing water pump:
5 Kg-m (50 Nm)
• Nuts (9) fixing electro magnetic gasket:
0,75 Kg-m (7,5 Nm)
• Nuts at tube adapter at water pump inlet:
2,5 Kg-m (25 Nm)
• Nuts sound proofing upper cover:
0,5 Kg-m (5 Nm)
3) Fill again the refrigeration circuit (see 0B-8).
