2-6 BUMPERS, FRONT HOOD AND FRONTAL
FRONT HOOD ADJUSTMENTS
Longitudinal and transversal adjustment
Loose the four screws (1), adjust lengthwise and transversally
the hood and then fix it once adjusted.
Vertical adjustment
If one of the hod sides is no level with the fender, adjust loosing
or tightening hood cushion (2).
Hood lock adjustment
Loose lock hood assembly screws (3) of the bonnet closing
unit, adjust anchoring correctly and tighten screws (3).
1
2
3
