Shimadzu GC-2010 Plus User Manual

12 Injection Port
12.3 Removing and inserting the glass insert
115
GC-2010 Plus
(2) Use tweezers to remove the glass insert.
NOTE If the O-ring has become fixed, turn the O-ring using tweezers and then lift the glass insert. Do not
forcibly lift the glass insert with the O-ring fixed because it may break the glass.
Fig. 12.3.3
Glass insert
O-ring
Tweezers

Shimadzu GC-2010 Plus Specifications

General

Type	Gas Chromatograph
Model	GC-2010 Plus
Manufacturer	Shimadzu
Maximum Temperature Ramp Rate	120 °C/min
Detector Options	FID, TCD, ECD, FPD, NPD, MS
Electronic Flow Control (EFC)	Yes
Data Sampling Rate	Up to 250 Hz
Column Oven Temperature Range	Ambient +5°C to 450°C
Maximum Oven Heating Rate	120 °C/min
Injection Port	Split/Splitless, PTV
Display	LCD
