13 Detector
13.3 Thermal conductivity detector (TCD)
163
GC-2010 Plus
FILTER TIME CONSTANT
Selection: 4 ms/5 ms/10 ms/20 ms/50 ms/100 ms/200 ms/500 ms/1 s/2 s, Default: 200 ms
This constant affects the processing of the detector signal.
As the time constant increases, noise as well as the peak height are reduced.
Select the optimum value in accordance with the peak half width. (Refer to “13.4 Filter
Signal Time Constant”.)
SIGNAL OUTPUT PORT
Selection: Off/Ch1/Ch2/Ch3/Ch4, Default: (Channel is automatically assigned.)
Select the digital and analog signals output Channels. Four channels are available.
However, for analog output, only Ch1 and Ch2 are available.
BACKGROUND SIG. SAVE
Selection: Off/Buff 1/Buff 2, Default: Off
Background baseline signals can be saved for the purpose of background subtraction.
BACKGROUND SIG COMP.
Selection: Off /Buff 1/Buff 2, Default: Off
Subtracts the saved background signal baseline from the actual baseline. This pro-
duces a stable baseline despite considerable baseline fluctuations.
DET SIG SUBTRACTION
Selection: Off /DET#1/DET#2/DET#3/DET#4, Default: Off
Subtracts the detector signal of one detector from the signal of another detector. This
function is mainly used in a dual column flow line to subtract the data acquired without
an injection from the data acquired with an injection. The background signal is elimi-
nated.
For the details on “SIGNAL OUTPUT PORT”, “BACKGROUND SIG. SAVE”,
“BACKGROUND SIG COMP.” and “DET SIG SUBTRACTION”, refer to “13.5 Setting
the Output Signals”.
SIGNAL RANGE
Selection: ×1/×10
-1
/×10
-2
/×10
-3
/×10
-4
/, Default: ×10
-1
Multiplies the analog signal by the coefficient “10
-x
” for a linear analog signal type. If the
signal intensity of a peak is beyond the input range of the data processing unit is satu-
rated, for example, change the setting from “×1” to “×10
-1
”, from “×10
-2
” to “×10
-3
”. If the
peak is too small, for example, change the setting from “×10
-1
” to “×1”, from “×10
-3
” to
“×10
-2
”. In case of the digital signal, the signal is always output with “×1”.
SIGNAL ATTENUATION
Selection: ×1/×2
-1
/×2
-2
/×2
-3
/×2
-4
/, Default: ×2
-1
Multiplies the analog signal by the coefficient “2
-x
” for a wide analog signal type. If the
signal intensity of a peak is beyond the input range of the data processing unit, for
example, change the setting from “×1” to “×2
-1
”, from “×2
-2
” to “×2
-3
”. If the peak is too
small, for example, change the setting from “×2
-1
” to “×1”, from “×2
-3
” to “×2
-2
”. In case
of the digital signal, the signal is always output with “×1”.
ANALOG SIGNAL TYPE
Selection: Linear/Wide, Default: Linear
Set this item when the GC is connected to a Chromatopac in analog format.
Wide ... Select wide when connecting the GC to the C-R8A/C-R7A/C-R7A plus. with
the signal cable in the standard accessories.
The signal, raised to the 1/2 (one harf) power, is output from the GC; then, the
signal received by the Chromatopac is squared.
When connecting the GC to a C-R8A/C-R7A/C-R7A plus for the first time, or
replacing the Chromatopac, set the detector signal output to “Off” and perform
the wide range calibration. (For the wide range calibration procedure, refer to
“2.7 Connecting external device cables”.)
To Next Page
