16 Special Functions
16.7 Service and Maintenance
263
GC-2010 Plus
TEMP. PORT
Selection: NON/INJ1/ INJ2/DET1/DET2/AUX3/AUX4/AUX5, Default: NON
Specify the injection port heated zone where the flow controller tubing is connected.
This assosiates the flow controller to an injection port.
Q Detector gas flow controller settings
When installing detector flow control units, the names DET#1 to DET#4 are
automatically assigned starting with the one nearest to the GC.
Specify the to flow controller detector gas settings for each detector No. (DET#1 to
DET#4).
CONT. TYPE
For display only.
The type of each installed detector control unit is automatically recognized and displayed.
DET APC No.
For display only.
When the slot No. is selected for each installed detector gas flow controller, the name
DET APC 1 to DET APC 4 is automatically assigned to each flow controller.
UNIT TYPE
When an APC is installed, the APC type is displayed for the Slot No. selected.
“APC (1ch)” indicates an APC for ECD/TCD. “APC (2ch)” indicates an APC for FPD.
“APC (3ch)” indicates an APC for FID/FTD.
When manual flow controllers are selected for the SLOT No, “DET GAS” is
automatically displayed.
SLOT NO.
Selection: NON/SLOT1/ SLOT2/SLOT3/ SLOT4/SLOT5/ SLOT6/SLOT7/ SLOT8,
Default: NON
When a manual flow controller is installed, specify the installation location Slot No.
(SLOT1, SLOT3, SLOT5 and SLOT7 are available).
When a APC is installed, select an available Slot No..
Slot No. which have already been set cannot be selected.
HEATER PORT
Specify the detector heated zone where the flows controller tubing is connected.
This assosiates the flow controller to a detector.
TCD has two heated zones. (Upper row: PRE-TCD, Lower row: TCD)
NOTE Changes are not in effect until the GC has been turned off and on.
