Tektronix DSA70000/B Series

Commands Listed in Alphabetical Order
NOTE. This quer
y is only valid when the CURSor:XY:READOUT is set to
PRODuct. If the readout is set other than product, the IEEE representation of
NAN (Not a Number) is returned: 99.1000E+36.
Group
Cursor
Syntax
CURSor:XY:PRODUCT<x>?
Examples
CURSor:XY:PRODUCT1? might return :CURSOR:XY :PRODUCT1 806.4004E-3,
indicating that the product of the X position times the Y position for Cursor 1
is 806.4004 mVV.
CURSor:XY:RADIUS<x>? (Query Only)
This query-only command returns the radius of the specified cursor when the
CURSor:XY:READOUT is set to POLARCoord. The cursor is specified by x,
whichcanbe1or2.
NOTE. This query is only valid when the CURSor:XY:READOUT is set to
POLARCoord. If the readout is set other than polar coordinates, the IEEE
representation of NAN (Not a Number) is returned: 99.1000E+36.
Group
Cursor
Syntax
CURSor:XY:RADIUS<x>?
Examples
CURSor:XY:RADIUS2? might return :CURS OR:XY:RADIUS2 4.9600,
indicating that the Cursor 2 radius is 4.9600 V.
CURSor:XY:RATDELta? (Query Only)
This query-only command returns ratio of the difference between the cursors
X position and Y position (ΔY¸ΔX) when the CURSor:XY:READOUT is set
to RATio. The ratio is calculated as (Cursor 2 Y - Cursor 1 Y) ÷ (Cursor 2 X -
Cursor 1 X).
NOTE. This query is only valid when the CURSor:XY:READOUT is set to RATio.
If the readout is set other than ratio, the IEEE representation of NAN (Not a
Number) is returned: 99.1000E+36.
DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual 2-145
