Commands Listed in Alphabetical Order
MEASUrement:
MEAS<x>:REFLevel:ABSolute:HIGH
This command sets or queries the high reference level, and is the upper reference
level when MEASUrement:MEAS<x>:REFLevel:METHod is set to Absolute.
Measurement
s a re specified by x, which ranges from 1 through 8.
NOTE. This command affects the results of rise and fall measurements
Group
Measureme
nt
Syntax
MEASUrement:MEAS<x>:REFLev el:ABSolute:HIGH <NR3>
MEASUrement:MEAS<x>:REFLev el:ABSolute:HIGH?
Related Commands
MEASUrement:MEAS<x>:REFLevel:METHod
Arguments
<NR3> is the high reference level, in volts. The default is 0.0 V.
Examples
MEASUREMENT:MEAS1:REFLEVEL :ABSOLUTE:HIGH 1.71 sets the high
reference level to 1.71 V.
MEASUREMENT:MEAS1:REFLEVEL :ABSOLUTE:HIGH? might return
:MEASUREMENT:MEAS1:REFLEVE L:ABSOLUTE:HIGH 1.7100E+00, indicating
that the absolute high reference level is set to 1.71 V.
MEASUrement:MEAS<x>:REFLevel:ABSolute:LOW
This command sets or queries the low reference level, and is the lower reference
level when MEASUrement:MEAS<x>:REFLevel:METHod is set to Absolute.
Measurements are specified by x, which ranges from 1 through 8.
NOTE. This command affects the results of rise and fall measurements.
Group
Measurement
Syntax
MEASUrement:MEAS<x>:REFLev el:ABSolute:LOW <NR3>
MEASUrement:MEAS<x>:REFLev el:ABSolute:LOW?
Related Commands
MEASUrement:MEAS<x>:REFLevel:METHod
DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual 2-389
