Command Groups
Table 2-14: Alias Commands (cont.)
Command Description
ALIas:DEFine
Assigns a sequence of program messages
to an alias label
ALIas:DELEte
Removes a specified alias
ALIas:DELEte:ALL Deletes all existing aliases
ALIas:DELEte:NAMe
Removes a specified alias
ALIas:STATE Sets or returns the alias state
Calibration Com mand Group
The Calibration commands provide information about the current state of
instrument calibration and allow y ou to initiate internal signal path calibration
(SPC). Commands that are specific to factory calibration are not described in
this manual; however, they are described in the service manual (located on your
Pro
duct Software CD-ROM in PDF format). You can also order a printed copy
(see Recommended Accessories in the online help for the instrument).
Command
Description
CALibrate? Returns the internal and factory calibration
status
*CAL? Instructs the instrument to perform
self-calibration and returns the calibration
status when complete
CALibrate:CALProbe:CH<x>? Performs a probe calibration for the selected
channel and returns the calibration status
CALibrate:INTERNal Starts the internal signal path calibration
CALibrate:INTERNal:STARt Starts the internal signal path calibration
CALibrate:INTERNal:STATus? Returns the current status of the internal
signal path calibration
CALibrate:PRObestate:CH<x>? Returns the probe calibration status for the
probe of the selected c hannel
CALibrate:RESults? Returns the status of all calibration
subsystems without performing an SPC
operation
CALibrate:RESults:SPC? Returns the results of the last SPC operation
Cursor Command Group
Use the commands in the Cursor Command Group to control the cursor display
and readout. You can use these commands to control the setups for cursor 1 and
cursor 2, such as waveform source, cursor position, and cursor color.
DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual 2-13
