Commands Listed in Alphabetical Order
Arguments
<NR3> is the low
reference level, in volts. The default is 0.0 V.
Examples
MEASUREMENT:MEAS1:REFLEVE L:ABSOLUTE:LOW 0.0 V sets the low
reference level to 0.0 V.
MEASUREMENT:MEAS1:REFLEVE L:ABSOLUTE:LOW? might return
:MEASUREMENT:MEAS1:REFLEV EL:ABSOLUTE:LOW 0.0000E+00, indicating
that the absolute low reference level is set to 0.0 V.
MEASUrement:MEAS<x>:REFLevel:ABSolute:MID<x>
This command sets or queries the mid reference level for the “to” waveform
when taking a delay measurement, and is the 50% reference level when
MEASUrement:MEAS<x>:REFLevel:METHod is set to Absolute. Mid1 sets
the “from” waveform and Mid2 sets the “to” waveform when taking a delay
measurement. Measurements are specified by x, which ranges from 1 through 8.
NOTE. This command affects the results of period, frequency, delay, and all
cyclic measurements.
Group
Measurement
Syntax
MEASUrement:MEAS<x>:REFLe vel:ABSolute:MID<x> <NR3>
MEASUrement:MEAS<x>:REFLe vel:ABSolute:MID<x>?
Related Commands
MEASUrement:MEAS<x>:REFLevel:METHod
Arguments
<NR3> is the mid reference level, in volts. The default is 0 .0 V.
Examples
MEASUREMENT:MEAS1:REFLEVE L:ABSOLUTE:MID2 0.5 sets the mid reference
level for the delay waveform to 0.5 V.
MEASUREMENT:MEAS1:REFLEVE L:ABSOLUTE:MID2? might return
:MEASUREMENT:MEAS1:REFLEV EL:ABSOLUTE:MID2 0.5000E+00, indicating
that the absolute mid2 reference level is set to 0.5 V.
MEASUrement:MEAS<x>:REFLevel:METHod
This command specifies or queries the reference level units used for measurement
calculations. This command is equivalent to selecting Reference Levels from the
2-390 DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual
