Tektronix DSA70000/B Series Programmer's Manual

Commands Listed in Alphabetical Order
DD MON YYYY HH:M
M:SS.xxx xxx xxx xxx
DD MON YYYY is day, month, and year
HH:MM:SS is hours, minutes, and seconds
.xxx xxx xxx xxx is fractions of a second to picoseconds
Group
Horizontal
Syntax
HORizontal:FASTframe:TIMES tamp:ALL:<wfm>? < NR1>, <NR1>
Arguments
<NR1> specifies the selected “from” frame number within the specified waveform.
<NR1> specifies the selected “to” frame number within the specified waveform.
Examples
HORIZONTAL:FASTFRAME:TIMES TAMP:ALL:CH2? 4,1 might return
:HORIZONTAL:FASTFRAME:TIME STAMP:ALL:CH1 4,1,“02 Mar 2000
20:10:54.542 037 272 620” This is the list of time stamps from frame 1 through
frame 4 on Channel 1.
HORizontal:FASTframe:TIMEStamp:BETWeen:<wfm>? (Query Only)
This query-only command returns the relative trigger for the delta time between
the specified frames, within the specified waveform. Valid waveforms include
CH<x>, MATH<x> and REF<x>. The x variable can be expressed as an integer
ranging from 1 through 4.
The format of the delta time output is as follows:
HH:MM:SS.xxx xxx xxx xxx
HH:MM:SS is hours, minutes, and seconds
.xxx xxx xxx xxx is fractions of a second to picoseconds
Group
Horizontal
Syntax
HORizontal:FASTframe:TIMES tamp:BETWeen:<wfm>? <NR1>, <NR1>
Arguments
<NR1> specifies the selected “from” frame number within the specified waveform.
<NR1> specifies the selected “to” frame number within the specified waveform.
DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual 2-249
