Tektronix DSA70000/B Series Programmer's Manual

Commands Listed in Alphabetical Order
<NR2> specifies
the right position of the histogram box in percentage coordinates.
The default value is 70.0.
<NR2> specifie
s the bottom position of the histogram box in percentage
coordinates. The default value is 75.2.
Examples
HISTOGRAM:BOXPCNT 30.0,25.0,70.0,75 .0 sets the left boundary of the
histogram box to 30% of the graticule (3 divisions from the left edge); the top
boundary to 25% of the graticule (0.25 × 8 = 2.0 divis
ions from the top edge);
the right boundary to 70% of the graticule (7 divisions from the left edge); and
the bottom boundary to 75% of the graticule (0.75 × 8 = 6.0 divisions from the
top edge).
HISTOGRAM:BOXPCNT? might return :HISTOGRAM:BOX PCNT
30.0000,25.1000,70.0000,75 .2000.
HIStogram:COUNt (No Query Form)
This command (no query form) clears the count and statistics for the histogram
and the histogram source d ata. If the histogr
am is on, then counting restarts.
This command is equivalent selecting Waveform Histograms from the Measure
menu and then clicking the Reset button.
Group
Histogram
Syntax
HIStogram:COUNt RESET
Related Commands
HIStogram:BOX, HIStogram:BOXPcnt
Examples
HISTOGRAM:COUNT RESET clears the count and statistics for the histogram and
the histogram source data.
HIStogram:DATa? (Query Only)
This query-only command returns an ASCII comma-separated list of histogram
data numbers. This command returns 252 values for vertical histograms and 1000
values for horizontal histograms. The first and last value are not displayed, and
are used for over range and u nder range tracking.
NOTE. You must set the histogram state to ON before sending this query or the
system will generate an error indicating: “Source waveform is not active”.
DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual 2-233
