Commands Listed in Alphabetical Order
Group
Limit Test
Syntax
LIMit:STATus?
Examples
LIMIT:STATUS? might return :LIMIT:STATUS PASS, indicating that the limit
test is passing.
LIMit:STOPOnviolation
This command sets or queries whether acquisitions are stopped when the
waveform data exceeds the test limits.
NOTE. The command works only if the LT Limit Test option is enabled.
Group
Limit Test
Syntax
LIMit:STOPOnviolation {OFF|ON|<NR1> }
LIMit:STOPOnviolation?
Arguments
OFF disables the stop on violation feature.
ON enables the stop on violation feature so that when the waveform data exceeds
the limits set b y the limit test, acquisitions are stopped.
<NR1>= 0 disables the stop on violation feature; any other value enables the stop
on violation feature so that when the waveform data exceeds the limits set by the
limit test, acquisitions are stopped. For queries, a 0 is returned if the stop on
violation feature is off; a 1 is returned if the stop on violation feature is on.
Examples
LIMIT:STOPONVIOLATION 1 enables the stop on violation feature s o that when
the waveform data exceeds the limits set by the limit test, acquisitions are stopped.
LIMIT:STOPONVIOLATION? might return :LIMIT:STOPONVIOLATION 0,
indicating that the stop on violation feature is disabled.
LIMit:TEMPlate:DESTination
This command sets or queries the destination reference waveform that the
LIMit:TEMPlate:STORe command will use.
NOTE. The command works only if the LT Limit Test option is enabled.
DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual 2-275
