Commands Listed in Alphabetical Order
TRIGger:B:RE
SET:TRANsition
This command sets or queries the type of threshold required for a Transition
trigger reset.
Group
Trigger
Syntax
TRIGger:B:RESET:TRANsitio n {RISe|FALL}
TRIGger:B:RESET:TRANsitio n?
Related Commands
TRIGger:B:RESET:SOUrce, TRIGger:B:RESET:THReshold, TRIGger:B:
RESET:TYPe
Arguments
RISe indicates that a reset occurs when the trigger rises above the threshold level.
FALL indica tes that a reset occurs when the trigger falls below the threshold level.
Examples
TRIGGER:B:RESET:TRANSITIO N RISE allows the reset to occur if the trigger
rises above the threshold level.
TRIGGER:B:RESET:TRANSITIO N? might return
:TRIGGER:B:RESET:TRANSITI ON FALL, indicating that the reset will occur if
the trigger falls below the threshold level.
TRIGger:B:RESET:TYPe
This command sets or queries the type of A→B sequential t rigger reset. If the B
trigger reset is active, the reset criteria are part of the B triggering sequence. If the
reset conditions defined by the reset type are not met, the instrument must start
over searching for a new occurrence of the A event.
You must identify a trigger Source and Threshold for each reset type, except
for the Timeout trigger type.
NOTE. If a reset condition occurs, the reset criteria itself is reset and must start
over.
Group
Trigger
Syntax
TRIGger:B:RESET:TYPe {NONe|TIMEOut| STATE|TRANsitio n}
TRIGger:B:RESET:TYPe?
2-614 DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual
