Page #279 background image
Commands Listed in Alphabetical Order
Examples
LIMIT:COMPARE
:CH1 REF1
species REF1 as the t emplate waveform against
which to compare waveforms acquired using Channel 1.
LIMIT:COMPAR
E:CH2?
might return :LIMIT:COMPARE:CH2 REF4, indicating
thatthewaveformacquiredbyChannel2iscomparedtothetemplatewaveform
stored in REF4.
LIMit:COMp
are:MATH<x>
This command sets or queries the template against which to compare the math
waveform specied by x, which can be 1 through 4. The template can be a
waveform
saved in any of the reference locations (REF1 through REF4) or none.
NOTE. The command works only if the LT Limit Test option is enabled.
Group
Limit T
est
Syntax
LIMit:COMpare:MATH<x> {NONe|REF<x>}
LIMit:COMpare:MATH<x>?
Arguments
NONe argument turns off template testing for the math waveform specied by
MATH<x>.
REF<x> argument selects which reference waveform to use as the template against
which to compare the math waveform specied by MATH<x>.
Examples
LIMIT:COMPARE:MATH1 REF1 speci es REF1 as the template waveform against
whichtocomp
are Math 1 waveform.
LIMIT:COMPARE:MATH2? might return :LI MIT:COMPARE:MATH 2 REF4,
indicating
that the Math 2 waveform is compared to the template waveform stored
in REF4.
LIMit:COMpare:REF<x>
This comman d sets or queries the template against which to compare the reference
waveform specied by x, which can be 1 through 4. The template can be a
waveform saved in any of the reference locations (REF1 through REF4) or none.
NOTE. Th
e command works only if the LT Limit Test option is enabled.
DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual 2-267
